Volume

Calculate the volumes of the given solid shapes.

Level 1 Level 2 Level 3 Formulas Surface Area Description More 3D

This is level 2; Find the volume of compound solid shapes. Give non-exact answers correct to the nearest whole number of the indicated units. The diagrams are not to scale.

Shape1 Find the volume of this prism with dimensions:
Maximum height = 17cm
Minimum height = 12cm
length = 15cm
Width = 5cm
Top step length = 6cm

Working:

cm3 Correct Wrong
Shape2 A three dimensional, asymetrical letter T is made up of two cuboids both 6cm wide. Calculate the volume of the shape.

Working:

cm3 Correct Wrong
Shape3 A beach hut is in the shape of a triangular prism on a cuboid. Find the volume of the hut from the measurements given on the diagram to the nearest cubic metre.

Working:

cm3 Correct Wrong
Shape4 Use the information in the diagram of the wire frame model to calculate its volume to the nearest cubic metre.

Working:

cm3 Correct Wrong
Shape5 The model of a building to house a telescope is in the shape of a hemisphere on a cylinder. Calculate the volume of the model to the nearest cubic centimetre.

Working:

cm3 Correct Wrong
Shape6 An obelisc is made up of a cone on a cylinder as shown in the diagram. Calculate its volume to the nearest cubic metre.

Working:

cm3 Correct Wrong
Shape7 A hollow brass cone has an outer radius of 60cm and an inner radius of 50cm. The outer height is 90cm and the inner height is 70cm. Find the volume of brass in the cone to the nearest cubic centimetre.

Working:

cm3 Correct Wrong
Shape8 Twenty ball bearings each with a radius of 5cm are melted down and cast into a cuboid of lenght 20cm and width 40cm. What is the height of this cuboid to the nearest centimetre?

Working:

cm3 Correct Wrong
Shape9 Find the volume (to the nearest cubic centimetre) of a hexagonal based pyramid mounted on a plynth in the shape of a hexagonal prism of the same cross section as the base of the pyramid. If the area of the hexagon is 0.5m2 and the height of both the pyramid and the prism are 25cm.

Working:

cm3 Correct Wrong
Shape10 A gold ingot in the shape of a cuboid (21cm x 8cm x 9cm) is melted down then cast in the shape of a cone with base radius 155mm. How tall is this cone assuming all of the gold was used? Give your answer to the nearest centimetre.

Working:

cm3 Correct Wrong
Check

Instructions

Try your best to answer the questions above. Type your answers into the boxes provided leaving no spaces. As you work through the exercise regularly click the "check" button. If you have any wrong answers, do your best to do corrections but if there is anything you don't understand, please ask your teacher for help.

When you have got all of the questions correct you may want to print out this page and paste it into your exercise book. If you keep your work in an ePortfolio you could take a screen shot of your answers and paste that into your Maths file.
